Specifications
| Model No. | H.265 4HDD 40 Channel NVR |
|---|---|
| INPUT | |
| Video Input | 40-ch |
| Max Resolution | 12MP |
| Two-way Audio Input | 1-ch, 3.5mm |
| Bandwidth | Income 200Mbps; Outgoing 200Mbps |
| OUTPUT | |
| HDMI/VGA Output | HDMI 1-ch, 3840×2160, 2560×1600, 2560×1440, 1920×1080, 1280×720, 800×600, 1024×768, 1366×768, 1440×900, 1280×800 VGA 1-ch, 1920×1080, 1280×720, 800×600, 1024×768, 1366×768, 1440×900, 1280×800 |
| Screen Split | 1/3/4/6/8/9/10/13/16/20/25/36/40/64 |
| Audio Output | 1xRCA |
| DECODING | |
| Decoding Format | IH+265/H.265/H.264 |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Preview Capability | 3x12MP, 4x8MP, 4x6MP, 5x5MP, 8x4MP, 9x3MP, 16x1080P, 32x720P, 40x4CIF |
| Synchronous Playback | 3x12MP, 4x8MP, 4x6MP, 5x5MP, 8x4MP, 9x3MP, 16x1080P, 16x720P |
| Records Encryption | Yes |
| HARD DISK | |
| SATA | 4 SATA interface for 2 HDDs |
| Capacity | Up to 10TB for each HDD |
| Array Type | JBOD, RAID0/1/5/6/10 |
| EXTERNAL INTERFACE | |
| Network Interface | 2xRJ45 self-adaptive 10/100/1000 Mbps network interface |
| USB Interface | 1xUSB 2.0, 1xUSB 3.0 |
| NETWORK | |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, IGMP, QoS, IPV4, IPV6, Multicast, ARP, UDP, SNMP, SSL, Telnet, RTMP, NFS |
| System Compatibility | ONVIF (PROFILE S/T/G) |
| GENERAL | |
| Web Version | Web6 |
| Language | English |
| Operating Conditions | -10°C~55°C, 10%~90% RH |
| Power Supply | 100~240V AC, 50~60 Hz |
| Consumption (without HDD) | ≤25W (without HDD) |
| Chassis | 1.5U |
| Dimensions | 75×347×440mm, (2.95×13.66×17.32 inch) |
| Weight (without HDD) | 3.35Kg (7.38lb) |
