HARDWARE FEATURES | |
---|---|
Processor | Qualcomm 750MHz CPU, MIPS 74Kc |
Memory | 128 MB DDR2 RAM, 16 MB Flash |
Interface | 1 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button |
Power Supply | Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27V DC |
Dimensions ( W x D x H ) | 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) |
Antenna Gain | 23 dBi |
Antenna Beamwidth | 9° (Azimuth)/7° (Elevation) |
Protection | 15 KV ESD Protection 6 KV Lightning Protection |
Enclosure | Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design |
WIRELESS FEATURES | |
---|---|
Wireless Standards | IEEE 802.11a/n/ac |
Wireless Speeds | Up to 867 Mbps (80 MHz, Dynamic) Up to 400 Mbps (40 MHz, Dynamic) Up to 173.4 Mbps (20 MHz, Dynamic) |
Frequency | 5.15–5.85 GHz |
Transmit Power | Max. 27 dBm (Adjustable power by 1dBm) |
