PRAMA PT-NR1A04-Q1 Network Video Recorder

Product Description

Video and Audio Incoming bandwidth 160 Mbps Outgoing bandwidth 80 Mbps HDMI output 1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz VGA output 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz Video output mode HDMI/VGA simultaneous output CVBS output N/A Audio output 1-ch, RCA (Linear, 1 KΩ) Two-way audio input 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) IP video input 16-ch Up to 8 MP resolution Auxiliary Interface SATA 2 SATA interfaces Capacity Up to 8 TB capacity for each disk USB interface Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 Network Remote connection 64 Network protocol TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS Network interface 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface Decoding Recording resolution 8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF Stream type Video, Video & Audio Audio compression G.711ulaw/G.711alaw/G.722/G.726 Decoding format H.265+/H.265/H.264+/H.264 Synchronous playback 16-ch Capability 1-ch@8 MP (30 fps)/5-ch@1080p (30 fps) General Consumption (without HDD) ≤ 15 W Working temperature -10 °C to 55 °C (14 °F to 131 °F) Power supply 12 VDC, 3.33 A Working humidity 10% to 90%
